Hot-Dip Galvanized Battery Chicken Cage with Automatic Feeding System and Customizable Dimensions

Delivery Time : 25 days

Model Number : KXD-SS7

Ventilation : Adjustable Vents

MOQ : 500 sqm

Packaging Details : steel pallet

Colors : Custom as Demands

Supply Ability : 500000 tons/month

Cell Capacity : 8 hens per cell

Price : USD 20,000.00-100,000.00

Window : Aluminum

Certification : ISO/CE/SGS

Dimensions : Customizable

Brand Name : KXD

Cage Size : 180×60×45cm (customizable)

Place of Origin : Qingdao，China

Roof Material : Steel Cladding Sheet, Sandwich Panel

Contact Now

Multi Tiers Battery Cage Automatic H Type Battery Chicken Layer Cage

Advanced automated egg laying chicken cage system designed for efficient poultry farming operations with comprehensive features for manure management, feeding, and drinking water systems.

Cage System Features

Main frame constructed with zinc-free hot galvanized sheet with 275g/m² galvanized layer thickness
Cage wire features complete hot dip galvanizing process after welding for long service life
Innovative chicken side longitudinal connection with turn-over design prevents leakage and facilitates washing
Thread clamp design on adjusting plate prevents loss and improves operational efficiency
One side sealing injection molding pad net with baffle plate installation ensures chicken comfort and prevents leakage

Hot-Dip Galvanized Battery Chicken Cage with Automatic Feeding System and Customizable Dimensions

Manure Management System

Longitudinal manure belt uses 1.0mm thick PP belt with smooth surface and high strength for clean feces removal
Horizontal stool cleaning frame features complete hot-dip galvanized treatment
PVC conveyor belt with seamless welding design and whole ring installation ensures durability and performance

Feeding System

Seeder type feeder with hot-dip galvanized sheet metal frame for corrosion resistance
Retractable homogenizer design overcomes uneven blanking caused by ground variations
Planter wheel with anti-pressure feet and anti-derailment electrical design for safety
Integrated circuit board control box with stop automatic correction function
Multiple feeding modes: manual, remote control, and timing automatic feeding with positioning capabilities

Drinking Water System

Fully upgraded automatic control system for reliable operation
Prevents leakage and reduces labor requirements
360° side hit drinking nipple design with water drops hanging beads to stimulate drinking

Feed Silo & Delivery System

Standard external ladder with protective railings for safe access
Closed design with automatic feeding improves management efficiency and reduces cross infections
Imported feed auger and white PVC feed pipe with detachable high strength wear-resistant nylon elbow
Manual feeding box included for emergency situations to ensure timely chicken feeding
